138 Maintenance and Troubleshooting
9
Maintenance of the Chip Priming Station
Replacing the Gasket
2 Pull out the old silicone gasket with your fingers or tweezers. See Figure 7
on page 138 for a disassembled adapter.
Figure 7 Syringe adapter with disassembled gasket
3 Insert a new silicone gasket and gently push into place.
4 Insert the syringe adapter into the chip priming station as described in
“Replacing the Syringe Adapter” on page 136 and reassemble the priming
station.
5 Check the priming station as described in “Checking the Chip Priming
Station for Proper Performance - Seal Test” on page 139.
6LOLFRQHJDVNHW
6\ULQJH
DGDSWHU
