A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 135 / 812

1.10.2. High Speed Timer Register List

Module Name

Base Address

High Speed Timer

0x01C60000

Register Name

Offset

Description

HS_TMR_IRQ_EN_REG

0x0

HS Timer IRQ Enable Register

HS_TMR_IRQ_STAS_REG

0x4

HS Timer Status Register

HS_TMR0_CTRL_REG

0x10

HS Timer 0 Control Register

HS_TMR0_INTV_LO_REG

0x14

HS Timer 0 Interval Value Low Register

HS_TMR0_INTV_HI_REG

0x18

HS Timer 0 Interval Value High Register

HS_TMR0_CURNT_LO_REG

0x1C

HS Timer 0 Current Value Low Register

HS_TMR0_CURNT_HI_REG

0x20

HS Timer 0 Current Value High Register

HS_TMR1_CTRL_REG

0x30

HS Timer 1 Control Register

HS_TMR1_INTV_LO_REG

0x34

HS Timer 1 Interval Value Low Register

HS_TMR1_INTV_HI_REG

0x38

HS Timer 1 Interval Value High Register

HS_TMR1_CURNT_LO_REG

0x3C

HS Timer 1 Current Value Low Register

HS_TMR1_CURNT_HI_REG

0x40

HS Timer 1 Current Value High Register

HS_TMR2_CTRL_REG

0x50

HS Timer 2 Control Register

HS_TMR2_INTV_LO_REG

0x54

HS Timer 2 Interval Value Low Register

HS_TMR2_INTV_HI_REG

0x58

HS Timer 2 Interval Value High Register

HS_TMR2_CURNT_LO_REG

0x5C

HS Timer 2 Current Value Low Register

HS_TMR2_CURNT_HI_REG

0x60

HS Timer 2 Current Value High Register

HS_TMR3_CTRL_REG

0x70

HS Timer 3 Control Register

HS_TMR3_INTV_LO_REG

0x74

HS Timer 3 Interval Value Low Register

HS_TMR3_INTV_HI_REG

0x78

HS Timer 3 Interval Value High Register

HS_TMR3_CURNT_LO_REG

0x7C

HS Timer 3 Current Value Low Register

HS_TMR3_CURNT_HI_REG

0x80

HS Timer 3 Current Value High Register
