Allwinner A20 - CSI0 Register Description

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 360 / 812
Register Name
Offset
Description
CSI0_C2_BUF_CTL_REG
0X228
CSI Channel_2 output buffer control register
CSI0_C2_BUF_STA_REG
0X22C
CSI Channel_2 status register
CSI0_C2_INT_EN_REG
0X230
CSI Channel_2 interrupt enable register
CSI0_C2_INT_STA_REG
0X234
CSI Channel_2 interrupt status register
CSI0_C2_HSIZE_REG
0X240
CSI Channel_2 horizontal size register
CSI0_C2_VSIZE_REG
0X244
CSI Channel_2 vertical size register
CSI0_C2_BUF_LEN_REG
0X248
CSI Channel_2 line buffer length register
CSI0_C3_F0_BUFA_REG
0X310
CSI Channel_3 FIFO 0 output buffer-A address register
CSI0_C3_F0_BUFB_REG
0X314
CSI Channel_3 FIFO 0 output buffer-B address register
CSI0_C3_F1_BUFA_REG
0X318
CSI Channel_3 FIFO 1 output buffer-A address register
CSI0_C3_F1_BUFB_REG
0X31C
CSI Channel_3 FIFO 1 output buffer-B address register
CSI0_C3_F2_BUFA_REG
0X320
CSI Channel_3 FIFO 2 output buffer-A address register
CSI0_C3_F2_BUFB_REG
0X324
CSI Channel_3 FIFO 2 output buffer-B address register
CSI0_C3_BUF_CTL_REG
0X328
CSI Channel_3 output buffer control register
CSI0_C3_BUF_STA_REG
0X32C
CSI Channel_3 status register
CSI0_C3_INT_EN_REG
0X330
CSI Channel_3 interrupt enable register
CSI0_C3_INT_STA_REG
0X334
CSI Channel_3 interrupt status register
CSI0_C3_HSIZE_REG
0X340
CSI Channel_3 horizontal size register
CSI0_C3_VSIZE_REG
0X344
CSI Channel_3 vertical size register
CSI0_C3_BUF_LEN_REG
0X348
CSI Channel_3 line buffer length register
4.1.5. CSI0 Register Description
4.1.5.1. CSI ENABLE REGISTER
Offset: 0x0000
Register Name: CSI0_EN_REG
Bit
Read/
Write
Default/He
x
Description
31:1
0
/
/
/
