Allwinner A20 - CSI0 Register List

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 358 / 812
Decode
F
V
H
P3
P2
P1
P0
Field 1 EAV (digital blanking)
0
1
1
0
1
1
0
Field 2 SAV
1
0
0
0
1
1
1
Field 2 EAV
1
0
1
1
0
1
0
Field 2 SAV (digital blanking)
1
1
0
1
1
0
0
Field 2 EAV (digital blanking)
1
1
1
0
0
0
1
Multi-Channel:
4.1.4. CSI0 Register List
Module Name
Base Address
CSI0
0x01C09000
Register Name
Offset
Description
CSI0_EN_REG
0X000
CSI enable register
CSI0_CFG_REG
0X004
CSI configuration register
CSI0_CAP_REG
0X008
CSI capture control register
CSI0_SCALE_REG
0X00C
CSI scale register
CSI0_C0_F0_BUFA_REG
0X010
CSI Channel_0 FIFO 0 output buffer-A address register
CSI0_C0_F0_BUFB_REG
0X014
CSI Channel_0 FIFO 0 output buffer-B address register
