Allwinner A20 - Transport Stream Register Description

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 749 / 812
6.13.4. Transport Stream Register Description
6.13.4.1. TSC CONTROL REGISTER
Offset: 0x00
Register Name: TSC_CTLR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:0
/
/
/
6.13.4.2. TSC STATUS REGISTER
Offset: 0x04
Register Name: TSC_STAR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:0
/
/
/
6.13.4.3. TSC PORT CONTROL REGISTER
Offset: 0x10
Register Name: TSC_PCTLR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:17
/
/
/
16
R/W
0
TSOutPort0Ctrl
TS Output Port0 Control
0 – SPI
1 – SSI
15:2
/
/
/
1
R/W
0
TSInPort1Ctrl
TS Input Port1 Control
0 – SPI
1 – SSI
0
R/W
0
TSInPort0Ctrl
TS Input Port0 Control
