TSG_CTLR
TSG + 0x00
TSG Control Register
TSG_PPR
TSG + 0x04
TSG Packet Parameter Register
TSG_STAR
TSG + 0x08
TSG Status Register
TSG_CCR
TSG + 0x0c
TSG Clock Control Register
TSG_BBAR
TSG + 0x10
TSG Buffer Base Address Register
TSG_BSZR
TSG + 0x14
TSG Buffer Size Register
TSG_BPR
TSG + 0x18
TSG Buffer Pointer Register
TSF_CTLR
TSF + 0x00
TSF Control Register
TSF_PPR
TSF + 0x04
TSF Packet Parameter Register
TSF_STAR
TSF + 0x08
TSF Status Register
TSF_DIER
TSF + 0x10
TSF DMA Interrupt Enable Register
TSF_OIER
TSF + 0x14
TSF Overlap Interrupt Enable Register
TSF_DISR
TSF + 0x18
TSF DMA Interrupt Status Register
TSF_OISR
TSF + 0x1c
TSF Overlap Interrupt Status Register
TSF_PCRCR
TSF + 0x20
TSF PCR Control Register
TSF_PCRDR
TSF + 0x24
TSF PCR Data Register
TSF_CENR
TSF + 0x30
TSF Channel Enable Register
TSF_CPER
TSF + 0x34
TSF Channel PES Enable Register
TSF_CDER
TSF + 0x38
TSF Channel Descramble Enable Register
TSF_CINDR
TSF + 0x3c
TSF Channel Index Register
TSF_CCTLR
TSF + 0x40
TSF Channel Control Register
TSF_CSTAR
TSF + 0x44
TSF Channel Status Register
TSF_CCWIR
TSF + 0x48
TSF Channel CW Index Register
TSF_CPIDR
TSF + 0x4c
TSF Channel PID Register
TSF_CBBAR
TSF + 0x50
TSF Channel Buffer Base Address Register
TSF_CBSZR
TSF + 0x54
TSF Channel Buffer Size Register
TSF_CBWPR
TSF + 0x58
TSF Channel Buffer Write Pointer Register
TSF_CBRPR
TSF + 0x5c
TSF Channel Buffer Read Pointer Register
TSD_CTLR
TSD + 0x00
TSD Control Register
TSD_STAR
TSD + 0x04
TSD Status Register
TSD_CWIR
TSD + 0x1c
TSD Control Word Index Register
TSD_CWR
TSD + 0x20
TSD Control Word Register
