Port C(PC)
Multiplex Function Select
PC11
NDQ3
SDC2_D3
PC12
NDQ4
PC13
NDQ5
PC14
NDQ6
PC15
NDQ7
PC16
NWP
PC17
NCE2
PC18
NCE3
PC19
NCE4
SPI2_CS0
EINT12
PC20
NCE5
SPI2_CLK
EINT13
PC21
NCE6
SPI2_MOSI
EINT14
PC22
NCE7
SPI2_MISO
EINT15
PC23
SPI0_CS0
PC24
NDQS
Port C(PC) Multiplex Function Select Table
Port D(PD)
Multiplex Function Select
PD0
LCD0_D0
LVDS0_VP0
PD1
LCD0_D1
LVDS0_VN0
PD2
LCD0_D2
LVDS0_VP1
PD3
LCD0_D3
LVDS0_VN1
PD4
LCD0_D4
LVDS0_VP2
PD5
LCD0_D5
LVDS0_VN2
PD6
LCD0_D6
LVDS0_VPC
PD7
LCD0_D7
LVDS0_VNC
PD8
LCD0_D8
LVDS0_VP3
PD9
LCD0_D9
LVDS0_VN3
PD10
LCD0_D10
LVDS1_VP0
PD11
LCD0_D11
LVDS1_VN0
PD12
LCD0_D12
LVDS1_VP1
PD13
LCD0_D13
LVDS1_VN1
PD14
LCD0_D14
LVDS1_VP2
