3.1.4.42. CSC2 U/R CONSTANT REGISTER
Offset: 0x1DC
Register Name: MP_OCSCURCONS_REG
Bit
Read/W
rite
Default/
Hex
Description
31:14
/
/
/
13:00
R/W
CSC2_URCONS
the U/R constant
the value equals to coefficient*2
4
3.1.4.43. CSC2 V/B COEFFICIENT REGISTER
Offset:
G/Y component: 0x1E0
R/U component: 0x1E4
B/V component: 0x1E8
Register Name: MP_OCSCVBCOEF_REG
Bit
Read/W
rite
Default/
Hex
Description
31:13
/
/
/
12:00
R/W
CSC2_VBCOEF
the V/B coefficient
the value equals to coefficient*2
10
3.1.4.44. CSC2 V/B CONSTANT REGISTER
Offset: 0x1EC
Register Name: MP_OCSCVBCONS_REG
Bit
Read/W
rite
Default/
Hex
Description
31:30
/
/
/
13:00
R/W
CSC2_VBCONS
the V/B constant
the value equals to coefficient*2
4
