A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 349 / 812
PS=0x10
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
B1
G1
R1
A1
B0
G0
R0
A0
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
PS=0x11
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
B0
G0
R0
A0
B1
G1
R1
A1
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
PS=1xxx, the R component is swapped with B component
16-bpp @ A1R5G5B5 mode
PS=0x00
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
A1
R1
G1
B1
A0
R0
G0
B0
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
PS=0x01
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
A0
R0
G0
B0
A1
R1
G1
B1
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
PS=0x10
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
B1
G1
R1
A1
B0
G0
R0
A0
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
PS=0x11
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
B0
G0
R0
A0
