4.1.5.20. CSI CHANNEL_1 FIFO 1 OUTPUT BUFFER-A ADDRESS REGISTER
Offset Address: 0X0118
Register Name: CSI0_C1_F1_BUFA_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C1F1_BUFA
FIFO 1 output buffer-A address
4.1.5.21. CSI CHANNEL_1 FIFO 1 OUTPUT BUFFER-B ADDRESS REGISTER
Offset Address: 0X011C
Register Name: CSI0_C1_F1_BUFB_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C1F1_BUFB
FIFO 1 output buffer-B address
4.1.5.22. CSI CHANNEL_1 FIFO 2 OUTPUT BUFFER-A ADDRESS REGISTER
Offset Address: 0X0120
Register Name: CSI0_C1_F2_BUFA_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C1F2_BUFA
FIFO 2 output buffer-A address
4.1.5.23. CSI CHANNEL_1 FIFO 2 OUTPUT BUFFER-B ADDRESS REGISTER
Offset Address: 0X0124
Register Name: CSI0_C1_F2_BUFB_REG
Bit
Read/W
rite
Default/
Hex
Description
31:00
R/W
0
C1F2_BUFB
FIFO 2 output buffer-B address
4.1.5.24. CSI CHANNEL_1 OUTPUT BUFFER CONTROL REGISTER
Offset Address: 0X0128
Register Name: CSI0_C1_BUF_CTL_REG
