A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 409 / 812
Register Name
Offset
Description
TCON1_CTL_REG
0x0090
TCON1 control register
TCON1_BASIC0_REG
0x0094
TCON1 basic timing register0
TCON1_BASIC1_REG
0x0098
TCON1 basic timing register1
TCON1_BASIC2_REG
0x009C
TCON1 basic timing register2
TCON1_BASIC3_REG
0x00A0
TCON1 basic timing register3
TCON1_BASIC4_REG
0x00A4
TCON1 basic timing register4
TCON1_BASIC5_REG
0x00A8
TCON1 basic timing register5
TCON1_IO_POL_REG
0x00F0
TCON1 IO polarity register
TCON1_IO_TRI_REG
0x00F4
TCON1 IO control register
TCON_CEU_CTL_REG
0x0100
TCON CEU control register
TCON_CEU_MUL_RR_REG
0x0110
TCON CEU coefficient register0
TCON_CEU_MUL_RG_REG
0x0114
TCON CEU coefficient register1
TCON_CEU_MUL_RB_REG
0x0118
TCON CEU coefficient register2
TCON_CEU_ADD_RC_REG
0x011C
TCON CEU coefficient register3
TCON_CEU_MUL_GR_REG
0x0120
TCON CEU coefficient register4
TCON_CEU_MUL_GG_REG
0x0124
TCON CEU coefficient register5
TCON_CEU_MUL_GB_REG
0x0128
TCON CEU coefficient register6
TCON_CEU_ADD_GC_REG
0x012C
TCON CEU coefficient register7
TCON_CEU_MUL_BR_REG
0x0130
TCON CEU coefficient register8
TCON_CEU_MUL_BG_REG
0x0134
TCON CEU coefficient register9
TCON_CEU_MUL_BB_REG
0x0138
TCON CEU coefficient register10
TCON_CEU_ADD_BC_REG
0x013C
TCON CEU coefficient register11
TCON_CEU_RANGE_R_REG
0x0140
TCON CEU coefficient register12
TCON_CEU_RANGE_G_REG
0x0144
TCON CEU coefficient register13
TCON_CEU_RANGE_B_REG
0x0148
TCON CEU coefficient register14
TCON1_FILL_CTL_REG
0x0300
TCON1 fill data control register
TCON1_FILL_BEG0_REG
0x0304
TCON1 fill data begin register0
TCON1_FILL_END0_REG
0x0308
TCON1 fill data end register0
TCON1_FILL_DATA0_REG
0x030C
TCON1 fill data value register0
TCON1_FILL_BEG1_REG
0x0310
TCON1 fill data begin register1
TCON1_FILL_END1_REG
0x0314
TCON1 fill data end register1
TCON1_FILL_DATA1_REG
0x0318
TCON1 fill data value register1
