Offset: 0x300
Register Name: TCON1_FILL_CTL_REG
Bit
Read/
Write
Default/
Hex
Description
0: bypass
1: enable
30:0
/
/
/
5.1.4.35. TCON1 FILL DATA BEGIN REGISTER
Offset: 0x304
Register Name: TCON1_FILL_BEG0_REG
Bit
Read/
Write
Default/
Hex
Description
31:24
/
/
/
23:0
R/W
0
Fill_Begin
5.1.4.36. TCON1 FILL DATA END REGISTER
Offset: 0x308
Register Name: TCON1_FILL_END0_REG
Bit
Read/
Write
Default/
Hex
Description
31:24
/
/
/
23:0
R/W
0
Fill_End
5.1.4.37. TCON1 FILL DATA VALUE REGISTER
Offset: 0x30C
Register Name: TCON1_FILL_DATA0_REG
Bit
Read/
Write
Default/
Hex
Description
31:24
/
/
/
23:0
R/W
0
Fill_Value
