A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 458 / 812
Offset: 0x0c0
Register name: ACP_Pkt
BYTE
Read
/Write
Default
/Hex
Description
0x05
R/W
0x00
ACP_PB3
0x06
R/W
0x00
ACP_PB4
0x07
R/W
0x00
ACP_PB5
0x08
R/W
0x00
ACP_PB6
0x09
R/W
0x00
ACP_PB7
0x0a
R/W
0x00
ACP_PB8
0x0b
R/W
0x00
ACP_PB9
0x0c
R/W
0x00
ACP_PB10
0x0d
R/W
0x00
ACP_PB11
0x0e
R/W
0x00
ACP_PB12
0x0f
R/W
0x00
ACP_PB13
0x10
R/W
0x00
ACP_PB14
0x11
R/W
0x00
ACP_PB15
0x12
R/W
0x00
ACP_EN
0: disable ACP packet TX
1: enable ACP packet TX
5.2.4.22. GENERAL_CONTROL_PACKET
Offset: 0x0e0-0x0e9
Register name: GP_Pkt
BYTE
Read
/Write
Default
/Hex
Description
0x00
R/W
0x00
GCP_HB0
Packet type
0x01
R/W
0x00
GCP _HB1
Packet version
0x02
R/W
0x00
GCP _HB2
Packet length
0x03
R/W
0x00
GCP _PB0
0x04
R/W
0x00
GCP _PB1
0x05
R/W
0x00
GCP _PB2
