Offset: 0xA4
Register Name: DEFE_DI_DIAGINTP_REG
Bit
Read/
Write
Default/
Hex
Description
Diagintp_th1
7
/
/
/
6:0
R/W
0x4F
TH0
Diagintp_th0
5.3.4.38. DEFE_DI_TEMPDIFF_REG
Offset: 0xA8
Register Name: DEFE_DI_TEMPDIFF_REG
Bit
Read/
Write
Default/H
ex
Description
31:13
/
/
/
12:8
R/W
0xF
TH
Temporal_th
7:0
/
/
/
5.3.4.39. DEFE_DI_SAWTOOTH_REG
Offset: 0xAC
Register Name: DEFE_DI_SAWTOOTH_REG
Bit
Read/
Write
Default/
Hex
Description
31:16
/
/
/
15:8
R/W
0x8
TH2
sawtooth_th2
7:0
R/W
0x14
TH1
Sawtooth_th1
5.3.4.40. DEFE_DI_SPATCOMP_REG
Offset: 0xB0
Register Name: DEFE_DI_SPATCOMP_REG
