A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 514 / 812
Offset: 0x124
Register Name: DEFE_CH0_HORZTAP1_REG
Bit
Read/
Write
Default/
Hex
Description
31
/
/
/
30:24
R/W
0x1
TAP7
Tap 7 offset in horizontal
23
/
/
/
22:16
R/W
0x1
TAP6
Tap 6 offset in horizontal
15
/
/
/
14:8
R/W
0x1
TAP5
Tap 5 offset in horizontal
7
/
/
/
6:0
R/W
0x1
TAP4
Tap 4 offset in horizontal
5.3.4.65. DEFE_CH0_VERTTAP_REG
Offset: 0x128
Register Name: DEFE_CH0_VERTTAP_REG
Bit
Read/
Write
Default/
Hex
Description
31
/
/
/
30:24
R/W
0x1
TAP3
Tap 3 offset in vertical
23
/
/
/
22:16
R/W
0x1
TAP2
Tap 2 offset in vertical
15
/
/
/
14:8
R/W
0x1
TAP1
Tap 1 offset in vertical
7
/
/
/
6:0
R/W
0x7F
TAP0
Tap 0 offset in vertical
