A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 517 / 812
5.3.4.70. DEFE_CH1_HORZPHASE_REG
Offset: 0x210
Register Name: DEFE_CH1_HORZPHASE_REG
Bit
Read/
Write
Default/
Hex
Description
31:20
/
/
/
19:0
R/W
0x0
PHASE
U/R component initial phase in horizontal (complement)
This value equals to initial phase * 2
16
5.3.4.71. DEFE_CH1_VERTPHASE0_REG
Offset: 0x214
Register Name: DEFE_CH1_VERTPHASE0_REG
Bit
Read/
Write
Default/
Hex
Description
31:20
/
/
/
19:0
R/W
0x0
PHASE
U/R component initial phase in vertical for top field (complement)
This value equals to initial phase * 2
16
5.3.4.72. DEFE_CH1_VERTPHASE1_REG
Offset: 0x218
Register Name: DEFE_CH1_VERTPHASE1_REG
Bit
Read/
Write
Default/
Hex
Description
31:20
/
/
/
19:0
R/W
0x0
PHASE
U/R component initial phase in vertical for bottom field
(complement)
This value equals to initial phase * 2
16
