Mono 8-bpp mode or palette 8-bpp mode : FBF = 0011
PS=00/11
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
P3
P2
P1
P0
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
PS=01/10
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
P0
P1
P2
P3
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Color 16-bpp mode : FBF = 0100 or 0101 or 0110 or 0111 or 1000
PS=00
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
P1
P0
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
PS=01
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
P0
P1
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
PS=10/11
Invalid
Color 24-bpp or 32-bpp mode : FBF = 1001 or 1010
PS=00/01
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
P0
