5.4.4.50. DE-HWC PALETTE TABLE
Offset:
0x4C00-0x4FFF
DE-HW palette table
Bit
Read/W
rite
Default/
Hex
Description
31:24
R/W
UDF
Alpha value
23:16
R/W
UDF
Red value
15:8
R/W
UDF
Green value
7:0
R/W
UDF
Blue value
The following figure (only with 2bpp mode) shows the RAM array used for hardware cursor palette lookup
and the corresponding colors output.
HWC Index memory
array
Output color
Hardware cursor index memory
& palette
HWC palette table
Color1
Color0
Color254
Color255
2bpp mode

0 R0 G0 B0

1 R1 G1 B1

254 R254 G254 B254

255 R255 G255 B255
3 2 0 2
1 3 2 2
3 3 0 1
bit7
bit0

2 R2 G2 B2

0 R0 G0 B0

2 R2 G2 B2

3 R3 G3 B3

1 R1 G1 B1

0 R0 G0 B0

3 R3 G3 B3

3 R3 G3 B3

2 R2 G2 B2

2 R2 G2 B2

3 R3 G3 B3

1 R1 G1 B1
5.4.4.51. SPRITE PALETTE TABLE
Offset:
0x4000-0x43FF
DE-sprite palette SRAM block
