Allwinner A20 - Page 714

A20 User Manual (Revision 1.2) Copyright © 2013 Allwinner Technology Co., Ltd. All Rights Reserved. Page 714 / 812
Offset: 0x34
Register Name: DA_TXCHMAP
Default Value: 0x7654_3210
Bit
Read/Write
Default
Description
101: 6
th
sample
110: 7
th
sample
111: 8
th
sample
19
/
/
/
18:16
R/W
4
TX_CH4_MAP
TX Channel4 Mapping
000: 1
st
sample
001: 2
nd
sample
010: 3
rd
sample
011: 4
th
sample
100: 5
th
sample
101: 6
th
sample
110: 7
th
sample
111: 8
th
sample
15
/
/
/
14:12
R/W
3
TX_CH3_MAP
TX Channel3 Mapping
000: 1
st
sample
001: 2
nd
sample
010: 3
rd
sample
011: 4
th
sample
100: 5
th
sample
101: 6
th
sample
110: 7
th
sample
111: 8
th
sample
11
/
/
/
10:8
R/W
2
TX_CH2_MAP
TX Channel2 Mapping
000: 1
st
sample
001: 2
nd
sample
010: 3
rd
sample
011: 4
th
sample
100: 5
th
sample
101: 6
th
sample
