6.13.4.36. TSD STATUS REGISTER
Offset: TSD+0x04
Register Name: TSD_STAR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:0
/
/
/
6.13.4.37. TSD CONTROL WORD INDEX REGISTER
Offset: TSD+0x1c
Register Name: TSD_CWIR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:3
/
/
/
6:4
R/W
0x0
CWI
Control Word Index
This value is the Control index for Control word access.
Range is from 0x00 to 0x7.
3:2
/
/
/
1:0
R/W
0x0
CWII
Control Word Internal Index
0 – Odd Control Word Low 32-bit, OCW[31:0];
1 – Odd Control Word High 32-bit, OCW[63:32];
2 – Even Control Word Low 32-bit, ECW[31:0];
3 – Even Control Word High 32-bit, ECW[63:0];
6.13.4.38. TSD CONTROL WORD REGISTER
Offset: TSD+0x20
Register Name: TSD_CWR
Default Value: 0x0000_0000
Bit
Read/Write
Default
Description
31:0
R/W
0x0
CWD
Content of Control Word corresponding to the TSD_CWIR
