NOTE
The adjustment of the rigid cutting disc must be
adapted to the respective operating conditions.
The optimum adjustment can only be determined
during field operation.
1. Raise the implement.
2. Secure the tractor and implement.
3. Remove the nut and washer
1
.
4. Remove the bolt
6
.
5. Loosen the nut
2
.
6. Move the bracket
5
to the desired height.
7. Install the bolt.
8. Install the nuts and washers and tighten them.
If the setting range is not enough, install the cutting
disc
4
at the desired height on the bracket.
9. Remove the nut and washers
3
.
10. Install the cutting disc at the desired height on the
bracket.
11. Install the nut and washer.
12. Check the adjustment of the rigid cutting discs on
the field after driving a short distance.
CMS-I-00005362
6.4.13.4 Adjusting the seed placement depth
NOTE
The adjustment of the seed placement depth must
be adapted to the respective operating conditions.
The optimum adjustment can only be determined
during field operation.
CMS-T-00005825-B.1
