When the coulter pressure beside the tractor
tracks is adjusted, the coulter pressure in the
tractor tracks is increased by the set value.
4. To check the setting after driving a short
distance,
see "Checking the placement depth".
6.4.23.3 Adjusting the running gear height
NOTE
In the factory settings, the running gear wheels
are installed in the centre position.
Special operating conditions can require a
different running gear height. In doing so, it
must be noted that the range of movement of
the seeding coulter is restricted. For example,
if the running gear height is increased, the set
placement depth may not be reached on very hilly
terrain.
1. Raise the implement.
2. Secure the machine.
3. Fix the height of the wheel
with a suitable aid.
4. Remove the bolts
.
5. Move the wheel to the desired position with a
suitable aid.
6. Install the bolts and tighten them.
7. After 5 hours of operation, check the bolt
connection for tight fit.
For implements with mechanical drives, the length of
the drive chain must be adjusted.
In the upper position, the chain must be shortened
by 3 links, and in the lower position, it must be
lengthened by 3 links.
8.
To adjust the length of the drive chain,
see "Replacing the gear wheel in the leading
wheel drive".
CMS-I-00005634
CMS-T-00008168-A.1
6 | Preparing the machine
Preparing the implement for operation
MG6660-EN-II | D.1 | 27.09.2021
147
