Installing the coulters with the PreTeC transport dolly
is described in the following.
9. lower the implement.
10. Move the transport dolly
with the tilted coulter
towards the frame
.
CMS-I-00005133
11. Raise the implement.
The depth control wheels
are resting on the
transport dolly
.
12. Loosen the belts
from the coulter.
13. Lift the implement further.
CMS-I-00005134
14. Install the coulter bracket.
15. For telescopic coulters
Tighten the bolts
to 160 Nm -180°,
or
For non-telescopic coulters
Tighten the bolts to 200 Nm.
CMS-I-00002039
16. To put the desired coulter into operation,
see "Coupling the air and fertiliser supply".
17. To put the desired coulter into operation,
see "Coupling the energy supply".
18. If the implement is equipped with a hydraulic
coulter pressure system,
see "Coupling the hydraulic supply".
6 | Preparing the machine
Preparing the implement for operation
MG6660-EN-II | D.1 | 27.09.2021
149
