System Control
ARM DDI 0500D Copyright © 2013-2014 ARM. All rights reserved. 4-178
ID021414 Non-Confidential
Register access is encoded as follows:
4.5.17 Instruction Set Attribute Register 3
The ID_ISAR3 characteristics are:
Purpose Provides information about the instruction sets implemented by the
processor in AArch32.
Usage constraints This register is accessible as follows:
Must be interpreted with ID_ISAR0, ID_ISAR1, ID_ISAR2, ID_ISAR4,
and ID_ISAR5. See:
• Instruction Set Attribute Register 0 on page 4-172.
• Instruction Set Attribute Register 1 on page 4-173.
• Instruction Set Attribute Register 2 on page 4-175.
• Instruction Set Attribute Register 4 on page 4-179.
• Instruction Set Attribute Register 5 on page 4-181.
Configurations ID_ISAR3 is architecturally mapped to AArch64 register
ID_ISAR3_EL1. See AArch32 Instruction Set Attribute Register 3 on
page 4-33.
There is one copy of this register that is used in both Secure and
Non-secure states.
Attributes ID_ISAR3 is a 32-bit register.
Figure 4-89 shows the ID_ISAR3 bit assignments.
Figure 4-89 ID_ISAR3 bit assignments
Table 4-173 ID_ISAR2 access encoding
coproc opc1 CRn CRm opc2
1111 000 0000 0010 010
EL0
(NS)
EL0
(S)
EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
--RORORORO RO
