12. Set the ConnectMode to C0. If you will be using the XPort Remote Host feature, and you are running 8bit
firmware versions 6.07.20 to 6.07.22 then set the ConnectMode to D4. If you are running 8bit firmware
versions 6.07.23 or above set the ConnectMode to D7.
ConnectMode (C0) ?
13. For all other settings please keep the default settings as shown below. If you do not want to change a value,
just press Enter to skip.
Remote IP Address : (000) .(000) .(000) .(000)
Remote Port (0) ?
DisConnMode (00) ?
FlushMode (00) ?
DisConnTime (00:00) ?:
SendChar 1 (00) ?
SendChar 2 (00) ?
14. If extra security is required, certain functionality can be disabled. Optionally type 6 (Security) followed by
Enter.
15. For the first two settings please keep the default settings as shown below. If you do not want to change a
value, just press Enter to skip.
Disable SNMP (N)
SNMP Community Name (public):
16. To disable the Telnet Configuration capability, set the Disable Telnet Setup option to Y. WARNING: Once
this option is disabled, the only way to re-configure the XPort device is to use the Diagnostics Tool within
Traka32.
Disable Telnet Setup (N) Y
17. For the next two settings please keep the default settings as shown below. If you do not want to change a
value, just press Enter to skip.
Disable TFTP Firmware Update (N)
Disable Port 77FEh (N)
18. To disable the Web Server Configuration capability, set the Disable Web Server option to Y.
Disable Web Server (N) Y
19. For the next setting please keep the default settings as shown below. If you do not want to change a value,
just press Enter to skip.
Disable ECHO ports (Y)
20. If a more complex password is required to protect the Telnet and/or Web Server Configuration capability, set
the Enable Enhanced Password to Y. It is also possible to change the password if there is already one set.
Enable Enhanced Password (Y) Y
Change the Password (N) 123456789
21. For the final setting please keep the default settings as shown below. If you do not want to change a value,
just press Enter to skip.
Disable Port 77F0h (N)
22. When you are happy with the configuration, type 9 (Save and exit) followed by Enter.
23. The device will automatically re-boot ready for use with the new settings. This will take approximately 10 to
20 seconds.
