Version 6.8 239 Mediant 2600 E-SBC
User's Manual 16. Quality of Experience
3. Configure a QoE Profile according to the parameters described in the table below.
4. Click Submit.
Table 16-1: Quality of Experience Profile Table Parameter Descriptions
Parameter Description
Index
[QOEProfile_Index]
Defines an index number for the new table record.
Profile Name
CLI: name
[QOEProfile_Name]
Defines an arbitrary name to easily identify the QoE Profile.
The valid value is a string of up to 20 characters.
Sensitivity Level
CLI: sensitivity-level
[QOEProfile_SensitivityLevel]
Defines the pre-configured threshold profile to use.
 [0] User Defined = Need to define thresholds per monitored
parameter in the Quality of Experience Color Rules table.
 [1] Low = Pre-configured low sensitivity thresholds.
 [2] Medium = Pre-configured medium sensitivity thresholds.
 [3] High = Pre-configured high sensitivity thresholds.
Reporting is done for small fluctuations in parameter values.
5. In the Quality of Experience Profile page, select the QoE Profile index row for which
you want to configure QoE thresholds, and then click the Quality of Experience
Color Rules link located below the table; the Quality of Experience Color Rules page
appears.
6. Click Add; the following dialog box appears:
Figure 16-3: Quality of Experience Page - Add Record Dialog Box
The figure above shows a configuration example where if the MOS value changes by
0.1 (hysteresis) to 3.3 or 3.5, the Green-Yellow threshold is crossed. The device
considers a change to 3.3 as a Yellow state (i.e., medium quality) and a change to 3.5
as a Green state.
7. Configure a QoE Color rule according to the parameters described in the table below.
8. Click Submit, and then save ("burn") your settings to flash memory.
Table 16-2: Quality of Experience Color Rules Table Parameter Descriptions
Parameter Description
Index
CLI: index
[QOEColorRules_ColorRuleIndex]
Defines an index number for the new table record.
