User's Manual 240 Document #: LTRT-42060
Mediant 2600 E-SBC
Parameter Description
Monitored Parameter
CLI: monitored-parameter
[QOEColorRules_monitoredParam
]
Defines the parameter to monitor and report.
 [0] MOS (default)
 [1] Delay
 [2] Packet Loss
 [3] Jitter
 [4] RERL [Echo]
Direction
CLI: direction
[QOEColorRules_direction]
Defines the monitoring direction.
 [0] Device Side (default)
 [1] Remote Side
Sensitivity Level
CLI: sensitivity-level
[QOEColorRules_profile]
Defines the sensitivity level of the thresholds.
 [0] User Defined = Need to define the thresholds in the
parameters described below.
 [1] Low = Pre-configured low sensitivity threshold values.
Thus, reporting is done only if changes in parameters'
values is significant.
 [2] Medium = (Default) Pre-configured medium sensitivity
threshold values.
 [3] High = Pre-configured high sensitivity threshold values.
Thus, reporting is done for small fluctuations in parameter
values.
Green Yellow Threshold
CLI: green-yellow-threshold
[QOEColorRules_GreenYellowThr
eshold]
Defines the parameter threshold values between Green (good
quality) and Yellow (medium quality) states.
The valid threshold values are as follows:
 MOS values are in multiples of 10. For example, to denote
a MOS of 3.2, the value 32 (i.e., 3.2*10) must be entered.
 Delay values are in msec.
 Packet Loss values are in percentage (%).
 Jitter is in msec.
 Echo measures the Residual Echo Return Loss (RERL) in
dB.
Green Yellow Hysteresis
CLI: green-yellow-hysteresis
[QOEColorRules_GreenYellowHys
teresis]
Defines the fluctuation (change) from the value configured for
the Green-Yellow threshold. When the threshold is exceeded
by this hysteresis, the device sends a report to the SEM
indicating this change.
Note: If the monitored parameter crosses two thresholds at
once (e.g., from Green to Red), the device ignores the
hysteresis value and reports the call state change to the SEM.
Yellow Red Threshold
CLI: yellow-red-threshold
[QOEColorRules_YellowRedThres
hold]
Defines the parameter threshold values between Yellow
(medium quality) and Red (poor quality) states.
The valid threshold values are as follows:
 MOS values are in multiples of 10. For example, to denote
a MOS of 3.2, the value 32 (i.e., 3.2*10) must be entered.
 Delay values are in msec.
 Packet Loss values are in percentage (%).
 Jitter is in msec.
 Echo measures the Residual Echo Return Loss (RERL) in
dB.
