AudioCodes Mediant 2600 User Manual

User's Manual 242 Document #: LTRT-42060
Mediant 2600 E-SBC
 To configure Bandwidth Profiles:
1. Open the Bandwidth Profile page (Configuration tab > VoIP menu > Quality of
Experience > Bandwidth Profile).
2. Click Add; the following dialog box appears:
Figure 16-4: Bandwidth Profile Page - Add Record
The figure above shows a configuration example where if the outgoing voice traffic
threshold of 64,000 increases by 80% (70% warning threshold plus 10% hysteresis) to
115,200 (64,000 plus 51,200), a Yellow state occurs and an alarm is sent. If the
threshold increases by 10%, a Red state occurs and an alarm is sent.
3. Configure a Bandwidth Profile according to the parameters described in the table
below.
4. Click Submit, and then reset the device with a save ("burn") to flash memory.
Table 16-3: Bandwidth Profile Table Parameter Descriptions
Parameter Description
Index
[BWProfile_Index]
Defines the index of the table row entry.
Name
CLI: name
[BWProfile_Name]
Defines an arbitrary name to easily identify the Bandwidth
Profile.
The valid value is a string of up to 20 characters.
Egress Audio Bandwidth
CLI: egress-audio-bandwidth
[BWProfile_EgressAudioBandwidth]
Defines the outgoing audio traffic threshold (in Kbps).
Ingress Audio Bandwidth
CLI: ingress-audio-bandwidth
[BWProfile_IngressAudioBandwidth]
Defines the incoming audio traffic threshold (in Kbps).
Egress Video Bandwidth
CLI: egress-video-bandwidth
[BWProfile_EgressVideoBandwidth]
Defines the outgoing video traffic threshold (in Kbps).
Ingress Video Bandwidth
CLI: ingress-video-bandwidth
[BWProfile_IngressVideoBandwidth]
Defines the incoming video traffic threshold (in Kbps).
Total Egress Bandwidth
CLI: total-egress-bandwidth
[BWProfile_TotalEgressBandwidth]
Defines the total (video and audio) outgoing bandwidth
threshold (in Kbps).
