AudioCodes Mediant 2600 - Page 271

Version 6.8 271 Mediant 2600 E-SBC
User's Manual 17. Control Network
 To configure a Proxy Set:
1. Open the Proxy Sets Table page (Configuration tab > VoIP menu > VoIP Network >
Proxy Sets Table).
Figure 17-5: Proxy Sets Table Page
2. Configure a Proxy Set according to the parameters described in the table below.
3. Click Submit, and then save ("burn") your settings to flash memory.
Table 17-6: Proxy Sets Table Parameter Description
Parameter Description
Web: Proxy Set ID
EMS: Index
CLI: configure voip > voip-network
proxy-set
[ProxySet_Index]
Defines an index number for the new table record.
Proxy Address
CLI: voip-network proxy-ip > proxy-
address
[ProxyIp_IpAddress]
Defines the address of the Proxy server. Up to 10 addresses
can be configured per Proxy Set.
The address can be defined as an IP address in dotted-decimal
notation (e.g., 201.10.8.1) or FQDN. You can also specify the
port in the following format:
 IPv4 address: <IP address>:<port> (e.g., 201.10.8.1:5060)
 IPv6 address: <[IPV6 address]>:<port> (e.g.,
[2000::1:200:200:86:14]:5060)
