SIP User's Manual 166 Document #: LTRT-12801
MP-500 MSBG
4. From the 'Profile Preference' drop-down list, select the priority of the Tel Profile, where
'1' is the lowest priority and '20' is the highest. If both IP and Tel profiles apply to the
same call, the coders and other common parameters (noted by an asterisk in the
description of the parameter TelProfile) of the preferred Profile are applied to that call.
If the Preference of the Tel and IP Profiles is identical, the Tel Profile parameters are
applied.
Note: If the coder lists of both IP and Tel Profiles apply to the same call, only the
coders common to both are used. The order of the coders is determined by the
preference.
5. Configure the Profile's parameters according to your requirements. For detailed
information on each parameter, refer to its description on the page in which it is
configured as an individual parameter.
6. From the 'Coder Group' drop-down list, select the Coder Group (refer to ''Configuring
Coder Groups'' on page 162) o
r the device's default coder (refer to ''Configuring
Coders'' on page 161) to whic
h you want to assign the Profile.
7. Repeat steps 2 through 6 to configure additional Tel Profiles (optional).
8. Click the Submit button to save your changes.
9. To save the changes to flash memory, refer to ''Saving Configuration'' on page 237.
3.4.5.5.4 Configuring IP Profiles
The 'IP Profile Settings' page allows you to define up to nine different IP Profiles. You can
later assign IP Profiles to routing rules in the call routing tables:
îš„ 'Tel to IP Routing' page (refer to ''Configuring the Tel to IP Routing Table'' on page
201)
îš„ 'IP to Hunt Group Routing'
page (refer to ''Configuring the IP to Trunk Group Routing''
on page 206).
The 'IP Profil
e Settings' page conveniently groups the different parameters according to
application to which they pertain:
îš„ Common Parameters: parameters common to all application types
îš„ Gateway Parameters: parameters applicable to gateway functionality
îš„ SBC Parameters: parameters that are applicable only to the SBC application
Notes:
• For a detailed description of each parameter in the 'IP Profile' table, refer
to its corresponding "global" parameter (configured as an individual
parameter).
• IP Profiles can also be implemented when operating with a Proxy server
(when the parameter AlwaysUseRouteTable is set to 1).
• You can also configure the IP Profiles using the ini file table parameter
IPProfile (refer to ''SIP Configuration Parameters'' on page 318).
