WARNING
Cutting tool. Keep hands and feet away. Never clean the tool while the engine is
running.
22. The battery is initially supplied without acid - Follow the instructions on filling in the manual.
23. Charging the battery should take at least 4 hours - Follow the instructions on charging in the
manual.
4 MAIN COMPONENTS (FIG. 2A)
1. Ground switch
2. Handlebar
3. Dead man lever
4. Dead man lever lock
5. Clutch lever
6. Horizontal handlebar adjustment lever
7. Independent power take-off engagement
lever
8. Forward/reverse shuttle lever
9. Differential locking lever
10. Battery housing
11. Gearshift lever
12. Vertical handlebar adjustment
13. Starter handle
14. Throttle trigger
15. Right brake command lever
16. Left brake command lever
17. Brake lever lock
5 ACCESSORY COMPONENTS (FIG. 2B)
1. On/off switch
2. Battery charge warning light
3. Oil pressure warning light
4. Single-pole socket for worklight
5. Lights selector
6. Power take-off engagement
7. Soil working tools
8. Depth skid
9. Rotor blade guard
10. Bar drive
11. Shoe
12. Cutter bar
13. Blade cover
14. Fuses
6 ASSEMBLY
WARNING
Always wear protective gloves during assembly operations.
WARNING
Ensure that all machine components are securely connected and the screws
tightened.
