• Pull out the blade attachment (F).
• Slide out the blade (G).
To assemble, perform the operations in reverse order.
14.8 ACCESSORIES
For details on all the accessories compatible with the machine, go to www.emak.it
15 POWER TAKE-OFF SHAFTS (FIG. 54)
The cultivator has two power take-off shafts for auxiliary applications:
• The bottom shaft is independent of the transmission and offers two speeds;
• The top shaft is synchronized with the transmission.
The specifications of the power take-off shafts are indicated in the illustration.)
16 GASOLINE ENGINE WIRING DIAGRAM (FIG. 55)
PO
Socket
K1M
Start relay
F2
Power outlet fuse 16 A
F1
Machine power supply fuse 30 A
M.Avv. Starter motor S1
Motor bulb
MCI
Internal combustion engine
G
Alternator
Q0
Starter key
R Governor
XS1
Plug for connection to engine unit
Color/cable key
N
Black
M Brown
R
Red
S
Pink
V Green G Gray
B
White
RN
Red Black
17 DIESEL ENGINE WIRING DIAGRAM (FIG. 56)
PO
Socket
H2
Battery warning light
F2
Power outlet fuse 16 A
K1M
Start relay
M.Avv. Starter motor F1
Machine power supply fuse 30 A
MCI
Internal combustion engine
S1
Motor bulb
Q0
Starter key
G
Alternator
H1
Oil warning light
R Governor
