170 S850 Operation & Maintenance Manual
DIAGNOSTIC SERVICE CODES (CONT'D)
Service Codes List (Cont’d)
CODE DESCRIPTION CODE DESCRIPTION
D7598 Drive controller in calibration mode H2806 Diverter short to ground
D7599
Drive AWS controller in wheel position
calibration mode
H2807 Diverter open circuit
H2905 High-flow short to battery
H1221 Right thumb switch out of range high H2906 High-flow short to ground
H1222 Right thumb switch out of range low H2907 High-flow open circuit
H1224 Right thumb switch not in NEUTRAL H2932 High-flow overcurrent
H1321 Left thumb switch out of range high H3028 Controller memory failure
H1322 Left thumb switch out of range low H3128 Interrupted power failure
H1324 Left thumb switch not in NEUTRAL H3648 Multiple ACD conflict error
H1421 Lift base pressure out of range high H3904 Left joystick in error
H1422 Lift base pressure out of range low H3912 Left joystick thumb switch not in NEUTRAL
H1502 Ride control output error ON H3913 Left joystick grip no communication
H1503 Ride control output error OFF H3916 Left joystick no communication
H1507 Ride control output open circuit H3928 Left joystick internal failure
H1528 Ride control output failure H3948 Left joystick multiple
H1602 Ride control relay error ON H4004 Right joystick in error
H1603 Ride control relay error OFF H4012 Right joystick thumb switch not in NEUTRAL
H2005 Boost solenoid short to battery H4013 Right joystick grip no communication
H2006 Boost solenoid short to ground H4016 Right joystick no communication
H2007 Boost solenoid open circuit H4028 Right joystick internal failure
H2032 Boost solenoid overcurrent H4048 Right joystick multiple
H2105 Reverse fan solenoid short to battery H4302 Horn error ON
H2106 Reverse fan solenoid short to ground H4303 Horn error OFF
H2107 Reverse fan solenoid open circuit H4423 Auxiliary not programmed
H2132 Reverse fan solenoid overcurrent H4497 Auxiliary controller programmed
H2305 Rear base output short to battery H4502 Right blinker error ON
H2306 Rear base output short to ground H4503 Right blinker error OFF
H2307 Rear base output open circuit H4602 Left blinker error ON
H2332 Rear base output overcurrent H4603 Left blinker error OFF
H2405 Rear rod output short to battery H4721 8 volt sensor supply out of range high
H2406 Rear rod output short to ground H4722 8 volt sensor supply out of range low
H2407 Rear rod output open circuit H7404 Main controller no communication
H2432 Rear rod output overcurrent
H2505 Diverter #2 short to battery L0102 Lights button error ON
H2506 Diverter #2 short to ground L0202
High-flow enable / auto idle enable button error
ON
H2507 Diverter #2 open circuit L0302 Auxiliary enable button error ON
H2605 Front base output short to battery L0402 Information button error ON
H2606 Front base output short to ground L7404 Main controller no communication
H2607 Front base output open circuit L7672 Left display panel needs programming
H2632 Front base output overcurrent
H2705 Front rod output short to battery M0116 Air filter not connected
H2706 Front rod output short to ground M0117 Air filter plugged
H2707 Front rod output open circuit M0216 Hydraulic / Hydrostatic filter not connected
H2732 Front rod output overcurrent M0217 Hydraulic / Hydrostatic filter plugged
H2805 Diverter short to battery M0309 System voltage too low
