171 S850 Operation & Maintenance Manual
DIAGNOSTIC SERVICE CODES (CONT'D)
Service Codes List (Cont’d)
CODE DESCRIPTION CODE DESCRIPTION
M0310 System voltage too high M1428 Fuel pull solenoid failure
M0311 System voltage extremely high M1502 Traction lock pull output error ON
M0314 System voltage extremely low M1503 Traction lock pull output error OFF
M0322 System voltage out of range low M1507 Traction lock pull output open circuit
M0409 Engine oil pressure too low M1528 Traction lock pull output failure
M0414 Engine oil pressure extremely low M1605 Traction lock hold solenoid short to battery
M0415 Engine oil pressure in shutdown M1606 Traction lock hold solenoid short to ground
M0421 Engine oil pressure out of range high M1607 Traction lock hold solenoid open circuit
M0422 Engine oil pressure out of range low M1705 Hydraulic lock valve short to battery
M0509 Hydraulic charge pressure too low M1706 Hydraulic lock valve short to ground
M0510 Hydraulic charge pressure too high M1707 Hydraulic lock valve open circuit
M0511 Hydraulic charge pressure extremely high M1732 Hydraulic lock valve overcurrent
M0514 Hydraulic charge pressure extremely low M1805 Lift spool lock output short to battery
M0515 Hydraulic charge pressure in shutdown M1806 Lift spool lock output short to ground
M0521 Hydraulic charge pressure out of range high M1807 Lift spool lock output open circuit
M0522 Hydraulic charge pressure out of range low M1832 Lift spool lock output overcurrent
M0610 Engine speed too high M2005 Two-speed primary solenoid short to battery
M0611 Engine speed extremely high M2006 Two-speed primary solenoid short to ground
M0613 Engine speed no signal M2007 Two-speed primary solenoid open circuit
M0615 Engine speed in shutdown M2032 Two-speed primary solenoid overcurrent
M0618 Engine speed out of range M2102 Glow plug output error ON
M0634 Engine speed invalid information from ECU M2103 Glow plug output error OFF
M0710 Hydraulic oil temperature too high M2107 Glow plug output open circuit
M0711 Hydraulic oil temperature extremely high M2128 Glow plug output failure
M0715 Hydraulic oil temperature in shutdown M2202 Starter output error ON
M0721 Hydraulic oil temperature out of range high M2203 Starter output error OFF
M0722 Hydraulic oil temperature out of range low M2207 Starter output open circuit
M0810 Engine coolant temperature too high M2228 Starter output failure
M0811 Engine coolant temperature extremely high M2302 Starter relay error ON
M0815 Engine coolant temperature in shutdown M2303 Starter relay error OFF
M0821 Engine coolant temperature out of range high M2402 Fuel pull relay error ON
M0822 Engine coolant temperature out of range low M2403 Fuel pull relay error OFF
M0909 Fuel level too low M2502 Traction pull relay error ON
M0921 Fuel level out of range high M2503 Traction pull relay error OFF
M0922 Fuel level out of range low M2602 Glow plug relay error ON
M1016 Hydraulic charge filter not connected M2603 Glow plug relay error OFF
M1017 Hydraulic charge filter plugged M2721 Throttle primary sensor out of range high
M1121 Seat bar sensor out of range high M2722 Throttle primary sensor out of range low
M1122 Seat bar sensor out of range low M2821 Throttle secondary sensor out of range high
M1128 Seat bar sensor failure M2822 Throttle secondary sensor out of range low
M1305 Fuel hold solenoid short to battery M3028 Controller memory failure
M1306 Fuel hold solenoid short to ground M3128 Interrupted power failure
M1307 Fuel hold solenoid open circuit M3204
ACS (AHC) no communication to Bobcat
controller
M1402 Fuel pull solenoid error ON M3304 Deluxe panel no communication
M1403 Fuel pull solenoid error OFF M3404 Deluxe panel in error
M1407 Fuel pull solenoid open circuit M3505 Hydraulic fan short to battery
