Brother MFC-9340CDW Service Manual

2-73
Confidential
■ Error code A500
Upon scanning a fax, the first side CIS white or black calibration data was not within the
normal range.
Error code A600
Though a fax was scanned again after A500 error, the first side CIS white or black calibration
data was not within the normal range.
Error code A700
The ROM color parameter does not match the first side CIS or second side CIS.
■ Error code A800
When an image was scanned and processed, an error was detected in ROM color parameter.
Error code A900
When an image was scanned and processed, a scanning error occurred.
■ Error code AC00
Upon scanning a fax, the second side white or black calibration data was not within the normal
range.
Scan Unable A5
Remove the original document. Turn the power off, then on again
Scan Unable A6
See Troubleshooting and routine maintenance chapter in User's Guide.
Print Unable A7
Turn the power off and then back on again.
Step Cause Remedy
1 First side/second side CIS unit
calibration data error
Perform "Function code 55". (Refer to
"1.4.18 Acquisition of white level data and
setting of CIS scanning area" in Chapter 5.)
2 First side CIS unit failure Replace the first side CIS unit.
3 Second side CIS unit failure Replace the second side CIS unit.
4 Main PCB failure Replace the main PCB ASSY.
-
Scan Unable A9
Step Cause Remedy
1 First side/second side CIS unit
calibration data error
Perform "Function code 55". (Refer to
"1.4.18 Acquisition of white level data and
setting of CIS scanning area" in Chapter 5.)
2 First side CIS unit failure Replace the first side CIS unit.
3 Second side CIS unit failure Replace the second side CIS unit.
4 Main PCB failure Replace the main PCB ASSY.
Scan Unable AC
Remove the original document. Turn the power off, then on again
Step Cause Remedy
1 Second side CIS unit calibration
data error
Perform "Function code 55". (Refer to
"1.4.18 Acquisition of white level data and
setting of CIS scanning area" in Chapter 5.)
2 Second side CIS unit failure Replace the second side CIS unit.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
