Brother MFC-9340CDW Service Manual

1-11
Confidential
1.5 Paper
1.5.1 Paper handling
Specifications are subject to change without notice.
1.5.2 Media specifications
*1
When you print on glossy paper, set only a single sheet on the manual feed slot.
*2
Legal size paper is not available in some regions outside U.S.A. and Canada.
Specifications are subject to change without notice.
1.5.3 Type and size of paper
The machine loads paper from the installed paper tray or the manual feed slot.
The names for the paper trays in the printer driver as follows:
Specifications are subject to change without notice.
Model
DCP-
9020CDN
DCP-
9020CDW
MFC-
9130CW
MFC-
9140CDN
MFC-
9330CDW
MFC-
9340CDW
Paper Input
Paper tray
250 sheets
Manual feed
slot
1 sheet
ADF 35 sheets
Paper
Output
Face-down 100 sheets (80 g/m
2
)
Face-up 1 sheet (Straight paper path)
2-sided Yes
N/A Yes
Model All models
Media type
Paper tray
Plain Paper, Thin Paper, Recycled Paper
Manual feed
slot
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper,
Bond paper, Label, Envelope, Env. Thin, Env.Thick, Glossy Paper
*1
2-sided Plain Paper, Thin Paper, Recycled Paper
ADF Plain Paper, Recycled Paper
Media weight Paper tray 60 to 105 g/m
2
(16 to 28 lb)
Manual feed
slot
60 to 163 g/m
2
(16 to 43 lb)
2-sided 60 to 105 g/m
2
(16 to 28 lb)
ADF 64 to 90 g/m
2
(17 to 24 lb)
Media size Paper tray
A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal
*2
, Folio
Manual feed
slot
Width: 76.2 to 216 mm (3.0 to 8.5 inch)
Length: 116 to 355.6 mm (4.57 to 14 inch)
2-sided Letter, Legal
*2
, Folio (for the U.S.A.),
A4 (for Europe, Asia, Oceania, China)
ADF Width 147.3 to 215.9 mm (5.8 to 8.5 inch)
Length 147.3 to 356.0 mm (5.8 to 14 inch)
The name for the paper trays The name for the paper trays in the printer driver
Paper tray Tray 1
Manual feed slot Manual

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
