Brother MFC-9340CDW Service Manual

5-15
Confidential
* For more information on the worker switch, refer to Reference.
<Operating procedure>
(1) Press the 1 and 0 keys in this order in the initial state of the maintenance mode.
"WSW00" is displayed on the LCD.
(2) Enter the number of worker switch to change.
The following is displayed on the LCD.
(3) Move the cursor to the selector you want to change with the < and > keys, and change the
value by pressing the 1 or 0 key.
(4) When you finish changing the value, press the SET key. This operation saves the newly
entered selector values onto the EEPROM and readies the machine for accepting a
worker switch number (WSW00).
(5) When worker switch setting is completed, press the Stop key to return the machine to the
initial state of the maintenance mode.
WSW73 Reserved (Change of the setting is prohibited)
WSW74 ADF stop control
WSW75 Paper ejecting distance of the switch back
WSW76 The limited number of the documents in reverse for paper ejection of the
one-sided scanning from ADF
WSW77 The limited number of the documents in reverse for paper ejection of the
two-sided from ADF
WSW78 Recording stop function when the drum reaches the end of life
WSW79 Function setting 27
WSW80 Copying speed control function
WSW81 Changing emulation function enable/disable setting
WSW82 AirPrint Icon No. setting
Memo:
- To cancel this operation and return the machine to the initial state of the maintenance
mode during the above procedure, press the Stop key.
- If there is a pause of more than one minute after a single-digit number is entered for
double-digit worker switch numbers, the machine will automatically return to the initial
state of the maintenance mode.
WSW No. Function
Selector 1 Selector 8

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
