Brother MFC-9340CDW Service Manual

1-13
Confidential
1.8 FAX (Only for the models with FAX function)
Specifications are subject to change without notice.
1.9 Copy
Specifications are subject to change without notice.
Specifications are subject to change without notice.
Model
DCP-
9020CDN
DCP-
9020CDW
MFC-
9130CW
MFC-
9140CDN
MFC-
9330CDW
MFC-
9340CDW
Modem Speed
N/A 33,600 bps (FAX)
Transmission speed N/A Approximately 2 seconds
(ITU-T Test Chart #1, Std resolution, JBIG)
ITU-T group N/A Super G3
Color FAX Sending N/A
Receiving N/A
Internet FAX
(ITU T.37 simple mode)
N/A Yes (Download only)
Model DCP-9020CDN
DCP-9020CDW
Copy Speed (A4/Letter) Monochrome/Full Color: Up to 18/19 ppm
(for the U.S.A., Europe)
Monochrome/Full Color: Up to 22/23 ppm (for China)
First copy
out time
From Ready
mode and
Paper tray
Monochrome/Full Color: Less than 19/22 seconds
From Sleep
mode and
Paper tray
Monochrome/Full Color: Less than 35/38 seconds
Resolution 600 x 600 dpi
Auto duplex scanning copy N/A
Model
MFC-9130CW MFC-9140CDN MFC-9330CDW MFC-9340CDW
Copy Speed (A4/Letter) Monochrome/
Full Color: Up
to 18/19 ppm
Monochrome/Full Color: Up to 22/23 ppm
First copy
out time
From Ready
mode and
Paper tray
Monochrome/Full Color: Less than 19/22 seconds
From Sleep
mode and
Paper tray
Monochrome/Full Color: Less than 35/38 seconds
Resolution 600 x 600 dpi
Auto duplex scanning copy N/A Yes

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
