3-117
Confidential
8.46 LED Control PCB ASSY
(1) Remove the two Taptite cup S M3x8 SR screws to remove the LED control PCB ASSY
from the Sub frame ASSY.
Fig. 3-163
Tpatite cup S M3x8 SR
Sub frame ASSY
LED control PCB ASSY
