3-116
Confidential
<Flat cable>
Fig. 3-162
LED flat cable (Y)
21±1 mm
21±1 mm
21±1 mm
21±1 mm
17±1 mm
17±1 mm
17±1 mm
17±1 mm
7.5 mm
7.5 mm
7.5 mm
7.5 mm
(259 mm)
(219 mm)
(219 mm)
(219 mm)
54.5 mm
74.5 mm
74.5 mm
54.5 mm
95±1 mm
95±1 mm
75±1 mm
Fold up flat cable along with the dotted line
Fold down flat cable along with the solid line
End of
supporting
tape
End of
supporting
tape
End of
supporting
tape
End of
supporting
tape
Conductor
Conductor
Conductor
Conductor
45°
45°
45°
45°
75±1 mm
LED flat cable (M)
LED flat cable (C)
LED flat cable (K)
<LED ASSY side>
<LED control
PCB ASSY side>
<LED ASSY side>
<LED control
PCB ASSY side>
<LED ASSY side>
<LED control
PCB ASSY side>
<LED ASSY side>
<LED control
PCB ASSY side>
