Brother MFC-9340CDW Service Manual

5-33
Confidential
1.4.16 Transfer of received fax data and log information (Function code 53)
<Function>
This function allows you to transfer received FAX data to another machine when the machine
cannot print the received data due to the printing mechanism failure. Activity reports,
communication lists, and machine log information can be also transferred.
<Operating procedure>
(1) Press the 5 and 3 keys in this order in the initial state of the maintenance mode.
"FAX TRANSFER" is displayed on the LCD.
- To check the number of received files, press the 1 key.
"1.NO. OF JOBS" is displayed on the LCD.
Press the SET key, and the number of received files appears, just as "NO. OF. JOBS: 10".
- To transfer the activity report only, press the 2 key.
"2.ACTIVITY" is displayed on the LCD.
- To transfer received files (together with the activity report), press the 3 key.
"3.DOCUMENTS" is displayed on the LCD.
Note that if there is no received file, the "NODOCUMENTS" appears on the LCD.
- To transfer the communication list for the latest communication, press the 4 key.
"4.COM.LIST (NEW)" is displayed on the LCD.
- To transfer the communication list for last three errors, press the 5 key.
"5.COM.LIST (ERR3)" is displayed on the LCD.
-
To transfer the maintenance information (the list in Function code 77), press the 6 key.
"6.MNT77 LIST" is displayed on the LCD.
(2) With the "2.ACTIVITY," "3.DOCUMENTS," "4.COM.LIST (NEW)," "5.COM.LIST (ERR3)"
or "6.MNT77 LIST" being displayed, press the SET key.
"ENTER NO. & SET" is displayed on the LCD.
(3) Enter the telephone number of the receiver machine and press the SET key again.
(4) The machine displays the "ACCEPTED" for approximately two seconds and starts dialing
to transfer data.
Note:
- Up to 99 files can be transferred simultaneously. When you transfer 100 files or
more, perform the following procedure multiple times.
- If there are both color and monochrome data the monochrome data will be
transferred first. If the receiver machine does not support the color function, the
sender machine cannot transfer color data, resulting in an error.
Note:
- Be sure to type the telephone number with the numerical keys. No one-touch dialing
is allowed in this procedure.
- No station ID will be attached. A cover page and end page as shown on the next
page will be automatically attached, instead.

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
