Brother MFC-9340CDW Service Manual

5-5
Confidential
1.4 Detailed Description of Maintenance-mode Functions
1.4.1 EEPROM parameter initialization (Function code 01, 91)
<Function>
This function initializes the setting values of the operation parameters, user switches, and
worker switches (WSW) registered in the EEPROM. Entering function code 01 initializes
almost all of the EEPROM areas, but entering 91 does not initialize some areas, as listed
below.
<Operating procedure>
(1) Press the 0 and 1 keys (or the 9 and 1 keys according to your need) in this order in the
initial state of the maintenance mode. The "PARAMETER INIT" appears on the LCD.
(2) Upon completion of parameter initialization, the machine returns to the initial state of the
maintenance mode.
Data item Function code 01 Function code 91
Printer switch
(Counter information)
These will not be
initialized.
These will not be
initialized.
Error History
MAC address
Operation lock of the control panel
password
These will be
initialized.
Secure Function Lock
Telephone function registration
Telephone book
Worker switch These will be
initialized.
User switches
(Items to be initialized when resetting to
the factory default settings)
Function settings except user switches
(Items except the factory default settings)
LAN settings
Emulation settings
Note:
- Function code 01 is for service personnel. Function code 91 is for user support.
- If the power is turned OFF while "PARAMERER INIT" is being displayed on the LCD, the
initialization of the EEPROM is not completed successfully. In this case, when the power
is turned ON next time, the EEPROM is automatically initialized. After the initialization is
completed, the machine returns to the initial state of the maintenance mode.
