8.8 Side Cover R
(1) Remove the two Taptite bind B M4x12 screws from the Side cover R.
Fig. 3-23
(2) Release the two Hooks and two Bosses on the upper side and three Hooks on the bottom
to remove the Side cover R from the Main body.
Fig. 3-24
Side cover R
Taptite bind B M4x12
Taptite bind B M4x12
<Right side>
Hook
Hook
Side cover R
Boss
Boss
Main body
Hook
<Right side>
