3-22
Confidential
Harness colors may be changed for any reason.
13 Speaker Unit
CN24
Hook
Front
<A view>
A view
Slit
Hook
Hook
Joint cover ASSY
Speaker unit
Speaker unit
Hook
Main PCB ASSY
Joint cover ASSY
Speaker harness (RD, BK)
Front
Speaker harness
(RD, BK)
