Brother MFC-9340CDW - Page 184

3-21
Confidential
Harness colors may be changed for any reason.
A view
<A view>
<B view>
B view
“A”
Hole
Hole
Hole
“A”
Front
Joint cover ASSY
Joint cover ASSY
Modem PCB ASSY
Hook
Sub frame ASSY
LED FG harness (BK)
LED FG harness (BK)
LED FG harness (BK)
