3-17
Confidential
Harness colors may be changed for any reason.
9 Eject Sensor PCB ASSY
CN1
CN10
Hook
Hook
“A”
“A”
Hook
Hook
Eject sensor PCB ASSY
Eject sensor
PCB ASSY
Main PCB ASSY
Line holder under
Front
Hook
Eject sensor harness (WH)
Eject sensor harness (WH)
