3-112
Confidential
Fig. 3-155
Tape
mm
158.5 mm
96
63.5
mm
mm
45°
45°
45°
(145 mm)
(380 mm)
(76.5 mm)
71.5 mm
Fold up flat cable along with the dotted line
Fold down flat cable along with the solid line
Conductor
100.5 mm
45°
90±1 mm
119±1 mm
0 to 1 mm
20±1
45±1 mm
78±1 mm
112±1 mm
140±1 mm
1±1 mm
Double-sided adhesive tape
<How to fold flat cable of the LED control flat cable>
Supporting tape
<To be connected to main PCB ASSY>
<To be connected to LED control PCB ASSY>
8 to 9 mm
45°
