Brother MFC-9340CDW - Page 318

3-155
Confidential
<How to fold flat cable of HVPS flat cable>
Fig. 3-225
Harness routing: Refer to " HVPS Flat Cable"
Center
Conductor
244±1
193±1
63±1
mm
mm
mm
45°
45°
45°
840 mm
±2 mm
45°
301±1
mm
26±1
mm
56±1
mm
89±1
mm
131±1 mm
376±1 mm
±2 mm
Fold up flat cable along with the dotted line
Fold down flat cable along with the solid line
Supporting tape
