Brother MFC-9340CDW Service Manual

5-40
Confidential
■ Printing of misregistration correction chart
<Operating procedure>
(1) Press the 6 key twice in the initial state of the maintenance mode.
"REGISTRATION" is displayed on the LCD.
(2) Press the or key to display "PRINT CHART" on the LCD.
(3) Press the SET key. "PRINTING" is displayed on the LCD, and printing of misregistration
correction chart (refer to fig. 5-15 (P5-41)) is printed. When printing is finished, "PRINT
CHART" is displayed on the LCD.
(4) Press the Cancel key to return the machine to the initial state of the maintenance mode.
■ Adjustment of inter-color position alignment (manual)
<Operating procedure>
(1) Press the 6 key twice in the initial state of the maintenance mode.
"REGISTRATION" is displayed on the LCD.
(2) Press the or key to display "SET REGISTRATION" on the LCD.
(3) Press the SET key. "1. MAGENTA=0" is displayed on the LCD.
Using the printed misregistration correction chart, identify the numeric value whose color
is the darkest in the pattern of (1) (Magenta Left) shown in fig. 5-15 (P5-41).
Press the or key to display the identified numeric value.
(4)
Press the SET key, and enter each numeric value of the patterns (2) to (9) in the same way.
(5) When you enter the numeric value of the pattern (9) (Yellow Right), "COMPLETED" is
displayed on the LCD.
(6) Press the Cancel key to return the machine to the initial state of the maintenance mode.
■ Adjustment of inter-color position alignment including registration sensor
calibration (auto)
<Operating procedure>
(1) Press the 6 key twice in the initial state of the maintenance mode.
"REGISTRATION" is displayed on the LCD.
(2) Press the or key to display "ADD REGISTRATION" on the LCD.
(3) Press the SET key. "PLS WAIT 66-1" is displayed on the LCD and sensitivity adjustment
of registration sensor and adjustment of inter-color position alignment are performed
automatically.
(4) When this operation is completed without an error, "COMPLETED" is displayed on the LCD.
(5) Press the Cancel key to return the machine to the initial state of the maintenance mode.
Memo:
If the Adjustment of inter-color position alignment including registration sensor calibration
(auto) fails while being in process,
" ERROR 66-1 " is displayed on the LCD.
Refer to the error message list on next page for the troubleshooting.

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
