2-58
Confidential
■ Error code 7000
After the registration rear sensor detects the end of paper pass, the eject sensor does not
detect paper pass.
<User Check>
- Remove the jammed paper.
■ Error code 7100
After the registration rear sensor detected that paper has passed, eject sensor continues to
detect paper pass.
<User Check>
- Remove the jammed paper.
Jam Inside
Open the Top Cover, pull out all four drum and toner cartridge assemblies
and remove the jammed paper.
Step Cause Remedy
1 Foreign object inside machine Remove foreign object.
2 Eject actuator that has come off
or that has been caught
Re-assemble the eject actuator.
3 Fuser cover installation failure Re-assemble the fuser cover.
4 Eject sensor PCB harness
connection failure
Check the eject sensor PCB harness
connection and reconnect it.
5 Fuser cover failure Replace the fuser cover.
6 Eject sensor failure Replace the eject sensor PCB ASSY.
7 Fuser unit failure Replace the fuser unit.
8 Main PCB failure Replace the main PCB ASSY.
Jam Rear
Open the Back Cover and remove the jammed paper, then press [Start].
Step Cause Remedy
1 Foreign object at the back of the
machine
Remove foreign object.
2 Eject actuator catching on some
position
Re-assemble the eject actuator.
3
Fuser cover installation failure Re-assemble the fuser cover.
4
Back cover installation failure Re-assemble the back cover.
5 Eject sensor failure Replace the eject sensor PCB ASSY.
6 Back cover failure Replace the back cover.
7 Eject roller 1 failure Replace the fuser cover.
8 Main PCB failure Replace the main PCB ASSY.
